What Should Proper High-Speed Converter Passband Flatness Look Like? (Part 2)

March 19, 2025
Part 1 covered the fundamental frequency-response measurement method and how to use it to measure the analog input bandwidth for an ADC. Part 2 discusses the DAC’s analog output and offers tips to avoid effects such as standing waves.

What you’ll learn:

  • How to evaluate a DAC’s analog output.
  • How to avoid effects such as standing waves from disturbing measurements.
  • How to adapt the fundamental frequency-response measurement method for use when digital upconversion is enabled.



For Part 1, click here.

Although using the fundamental frequency-response measurement method to measure the flatness frequency response of a digital-to-analog converter (DAC) is like the one described for analog-to-digital converters (ADCs) in Part 1, there are a few differences. The first step is to set up the DAC’s evaluation board with your preferred DAC configuration for testing. Your setup for the measurement should look like Figure 1.

This setup uses a PC to control a data-source board with a field-programmable gate array (FPGA) to provide and control the data that goes to the digital inputs of the DAC in the evaluation board. All of the necessary power and clock inputs connect to the DAC’s evaluation board as well as to the data-source board. It’s important to have all clock inputs and spectrum analyzers reference-locked by connecting the reference frequency outputs and inputs of the equipment.

Finally, the DAC analog output connects to a spectrum analyzer to measure its output in the frequency domain. We recommend frequency planning accordingly to prevent any spurs or harmonics from disrupting your measurement.

Some DACs can have different output modes or filters to suppress spurs or flatten the frequency response. You must know the mode in which the DAC is operating and if there are any restrictions when using that mode.

For example, some DACs employ an inverse sinc() filter that runs at the DAC’s update rate; this allows for the use of the inverse sinc() filter to flatten the frequency response of the sample-and-hold output. Other DACs have different filters for different Nyquist zones. For this reason, we don’t recommend sweeping across different Nyquist zones of the DAC when using internal filters without making sure that the mode of operation supports doing so, or if you can change the mode of operation accordingly.

After connecting the setup, verify the DAC’s output tone and make appropriate adjustments to the settings of the spectrum analyzer. Usually, when measuring the frequency passband flatness, a continuous-wave tone ensures that all of the DAC’s power output is in a single frequency bin. Try to make the span of the spectrum analyzer very narrow and reduce the resolution bandwidth until the fundamental amplitude is stable.
